.SENATOR COUNTRYMAN System- Boilers Installation & Users Guide.- PLASTIC PIPE - CAPACITIES OF EXPANSION VESSEL - EXPANSION VESSEL SIZING - WARNING SEALED SYSTEM - FILLING SYSTEM - SENATOR CONVENTIONAL FLUE INSTALLATION - BALANCED FLUE INSTALLATION (INTERNAL) 13-21 - CONNECTING OIL SUPPLY 21-22 - ELECTRICAL CONNECTION (INTERNAL & EXTERNAL).INTRODUCTION Thank you for choosing the INTERNAL or EXTERNAL COUNTRYMAN COMBI oil boiler please read the following carefully. To the installer This manual must be left with the householder by the installer who will instruct the user on the boiler operation. To the user Please read the user section of this manual to familiarize yourself with the boiler operation.USER INSTRUCTIONS Boiler Control Thermostat BOILER OPERATION The Boiler Control Thermostat responds to the temperature of the water within the boiler and switches power to the burner when heat is required. The burner has an independent control system which regulates the firing and (shut-off) of the burner.BOILER CONTROLS BOILER CONTROL THERMOSTAT The temperature of the water within the boiler is controlled and maintained by the Boiler Control Thermostat located on the boiler control panel.
TEMPERATURE SETTINGS: The Boiler Control Thermostat has a range of 50˚C to 80˚C. The recommended setting for the boiler control thermostat is: WINTER Heating and hot water supply 80˚C.SWITCHING THE BOILER OFF The boiler can be turned off by turning the rocker switch, located on the underside of control panel, to the OFF position. PLEASE NOTE: For longer periods of shutdown e.g. While away on holiday, switch OFF the mains (electrical supply) and turn OFF the OIL supply.RESTART - Check there is adequate oil in the storage tank.
Check oil supply valves are open. Switch on heating system (e.g. Depress the red Burner Reset Button on the burner Control Box, which will be illuminated. Both Burner Reset Button (illuminated) and the lockout Indicator on the Control Panel will go out and the burner will commence the ignition start sequence.REGULATIONS The installation of oil fired boilers should comply with the following standards and codes of practice.
Hopefully someone can tell me where I can get a diverter valve for a eurocal 70/90 combil boiler. I live in Scotland and my dad who is 75 lives in North Wales, so popping down to help sort anything is a nightmare and he has had problems with his boiler and the engineer has told him he needs a diverter valve but can't source one and the next option is to replace the boiler at a cost of £2k-£. View and Download Eurocal SENATOR installation & user manual online. Page 17 MODEL Flue 50/70 3” 70/90 3” 50/115 700- 1100 mm HIGH LEVEL ROOM.
BS5449 Forced circulation hot water heating systems for domestic use - BS5410-Part1 Oil installations up to 45kw. BS7593 Water treatment of hot water central heating systems.
BS7671 Electrical Regulations.BOILER LOCATION Sound levels should be discussed with the householder, as some people may be sensitive to low noise levels in a small room, as it may appear more annoying than in a larger room. Please Note installation should take into account of flue position (see diagram).
RECOMMENDED FLUE POSITION Please Note where the terminal is within 1 metre of any plastic material, such material should be protected from the effects of the combustion products of the fuel.INSTALLATION SERVICE REQUIREMENTS The boilers are serviced though an access panel at the front. A service access space of least 700mm should be made available at the front of the boiler. THE HEARTH The temperature of the surface below the boiler is less than 85˚C. If the floor under the boiler is of combustible material, then protection such as steel should be fitted between the boiler and the floor.PREFORMED PIPE WORK - 1 Of 22 mm section label Heating Flow - 1 Of 22 mm section label Heat Return - 1 Of 15 mm section label Cold Mains - 1 Of 15 mm section label Over Flow Preformed pipes, on the Internal system exit on the right hand side of the boiler. From the front view of the boiler.CAPACITIES OF EXPANSION VESSELS EXPANSION VESSEL SIZING Bs7074:Part1:1989 gives full details of accurate Safety Valve Setting @ method of calculating the required expansion Vessel charge and vessel capacity, assuming that full and accurate Initial System Pressure design information is available, particularly total (BAR GAUGE) system water content.SENATOR CONVENTIONAL FLUE INSTALLATION The boiler is supplied as standard for use with conventional flue.
The chimney must comply with building regulations and B S 5410. Factory made insulated chimneys are covered by B S 4543 Parts 2 & 3.BALANCED FLUE INSTALLATION VENTILATION AIR SUPPLY Air ventilation for balanced flue boilers is only required if the boiler is installed in a confined space e.g. This is to prevent over heating of components. BALANCED FLUE BOILERS 550mm /kW 25MM M IN 550mm /kW BOILER IN COMPARTMENT.LOW LEVEL BALANCED FLUE TERMINAL GUARD A Terminal Guard must be fitted to low level Flue Terminal below 2 metres and where persons or animals could come into contact with the terminal or if it could be subject to damage.
MODEL Flue 50/70.5. With boiler in position pass the flue assembly through the wall and bolt the bottom section of the flue to the boiler, insuring that square gasket is in between the boiler and the flue.
Eurocal 70 90 Manual Diagram
Attached the snorkel tube with clips to the flue. 7.MODEL Flue 50/70 3” 70/90 3” 50/115 700- 1100 mm HIGH LEVEL ROOM SEALED BALANCED FLUE DIMENSIONS INSTALLATION OF HIGH LEVEL BALANCED FLUE 1. Position boiler and Cut Hole in wall. Remember measure, mark, CHECK then cut. Remove Conventional flue ring from top of boiler.
REMOVE CASING LID REMOVE FOIL FIT SEALS AND.3. Fit Red inner seal and Black outer seal to flue connectors and extensions if required. Apply lubricant to the inner and outer seals. Taken care to only lubricant the lip of the seals.
Bolt bottom section of the flue to the boiler FIT SNORKEL TUBE insuring the square gasket is fitted in between the boiler and the flue.VERTICAL BALANCED FLUE MINIMUM 600MM FLASHING NOT SUPPLIED METRE 50/70 70/90 125MM The vertical flue is telescopic as supplied. The flue has a range of 1020 - 2400mm from the top of the boiler to the flashing. Extension kits of 300 and 950mm are available.INSTALLATION OF VERTICAL FLUE 1. Position boiler and cut hole/s in ceiling and roof. Remember measure mark,CHECK then cut. Remove conventional flue ring from top of boiler. Fit Red inner seal and Black outer seal to flue Remove lid Remove lid connectors and extensions if required.FITTING OF BF ADAPTOR Disconnect Burner Plug Loosen Bolt Remove Burner Fit B F Adaptor Gasket Remove C F Adaptor Peel backing sticky Fit B F Adaptor from B F adaptor Gasket Tighten bolt on burner Fit snorkel tube Internal view.FLUE KIT DESCRIPTION AND PART NUMBERS DESCRIPTION PART NUMBER 50-90,000BTU 1.
LOW LEVEL BALANCED FLUE STANDARD KIT1-80mm WALL THICKNESS FROM 150-450mm 2. LOW LEVEL BALANCED FLUE EXTENDED KIT2-80mm WALL THICKNESS FROM 260-600mm 3. 300mm FLUE EXTENSION KIT3-80mm 4.
HIGH LEVEL HORIZONTAL FLUE KIT4-80mm 5.OIL SUPPLY Diagrams of twin pipe oil supply systems BOILER FIRE VALVE SENSOR ALTERNATIVE FILTER POSITION FILL VENT SAW CUT INSIDE TANK TO PREVENT FIRE SYPHON VALVE OIL LEVEL FULL BURNER VALVE PAPER ELEMENT OIL LOWEST LEVEL FILTER OIL TANK Plastic tank shown steel tank also suitable BOILER.ELECTRICAL CONNECTION (INTERNAL & EXTERNAL SYSTEM) The electrical supply to the boiler must be wired using a double pole - isolating switch 240v/50hz fused at 5 amps. A multi 3 pin plug is included with the boiler, which connects with the boiler control panel.
